Wesco Utility Grade Infrastructure
Applicable To:
SAM-6865455 16AWG, SAM-6865500 18AWG
Marketing Claim Verified by UL Solutions
Wesco Utility Grade Infrastructure UTG40
Verification Method
Hybrid/Composite cable performance characteristics have been evaluated as outlined below to determine that the product satisfies the requirements of UTG40. For distances listed: POWER source = 95W @ 56VDC (NEC 726 Class 2 Power Supply – Limited Power Source) POWER edge = 30W / 60W / 75W @ 46VDC Note: Actual power delivered by cable in a specific installation is dependent on power supply voltage / wattage, required target voltage at edge, and actual cable temperature. For copper wire - Testing conditions: 40° C, 50%RH - Max input power not to exceed 100 Watts (per maximum Class 2 limits). - For each gauge size, confirm output power at the specified lengths below. For 16 AWG wire - At least 30 Watt power delivery at 460 meters - At least 60 Watt power delivery at 250 meters - At least 75 Watt power delivery at 185 meters For 18 AWG wire - At least 30 Watt power delivery at 300 meters - At least 60 Watt power delivery at 150 meters - At least 75 Watt power delivery at 120 meters For optical fiber - Testing conditions: 23° C nominal, 50%RH nominal. - Measure Bit Error Rate (BER) for 5 mins, with and without Forward Error Correction (FEC). - Calculate the confidence level with and without FEC. For 16 AWG Hybrid/Composite cables - Bit Error Rate (BER) of 1x10-12 at 400 Gbps with Forward Error Correction (FEC) over 460 meters of single-mode fiber. - Bit Error Rate (BER) of 1x10-12 at 400 Gbps without Forward Error Correction (FEC) over 460 meters of single-mode fiber. For 18 AWG Hybrid/Composite cables - Bit Error Rate (BER) of 1x10-12 at 400 Gbps with Forward Error Correction (FEC) over 300 meters of single-mode fiber. - Bit Error Rate (BER) of 1x10-12 at 400 Gbps without Forward Error Correction (FEC) over 300 meters of single-mode fiber.
About the Company
What is UL Verification?
UL Verification is an objective, science-based assessment that confirms the accuracy of marketing claims. Our independent assessment process scrutinizes the validity of specific advertising or promotional statements, giving you a way to separate verified fact from fiction.
